You can rest assured to buy 1KW 2KW 3KW Industrial Frequency Inverter from our factory.
● 7 working modes, in mains\solar\energy-saving mode, all with unattended, generator, backlight and output mode adjustable when needed; new status display bar, self-check fault, restart function;
● Protect against inductive lightning strike once when grounding is good;
● Alarm sound can be turned on and off automatically;
● Real-time digital display of mains charging current;
● Mains charging cut-off voltage is adjustable, and charging current has 11 gears precisely adjustable;
● Output 210V-240V adjustable;
● 50Hz/60Hz adjustable;
● Factory settings can be restored;
● Support various types of batteries, you can choose by yourself;
● Chinese and English can be switched by yourself;
● Independent mains activated lithium battery module;
● Integrated output-only and charging-only modules can reach double power under mains.
As the professional manufacturer, we would like to provide you 1KW 2KW 3KW Industrial Frequency Inverter.
Machine Model(FSY-PDD) | 10201/02/04 | 20201/02/04/05/06 | 30201/02/04/05/06 |
INPUT | |||
Battery Voltage | 12V/24V/48V | 12V/24V/48V/60V/72V | 12V/24V/48V/60V/72V |
Mains Voltage | 110V/220V | ||
Mains Power Range | 154-264VAC/185-264VAC | ||
Frequency | 50/60Hz | ||
OUTPUT | |||
Power | 1000W | 2000W | 3000W |
Voltage | 220V±5% | ||
Frequency | 50/60Hz | ||
Self-depletion | 10W | 15W | 20W |
Energy-saving idle consumption | 3W | 3W | 3W |
Waveform | Pure Sine Wave | ||
Transmission Time (AC to DC) | <8ms | ||
Transmission Time (DC to AC) | <8ms | ||
Output Voltage Regulation | 210V-240V | ||
Bypass Mode | yes | ||
Energy Saving Mode | yes | ||
Efficiency | ≥85% | ||
PROTECTION | |||
Input Protection | Overcurrent Protection | ||
Output Protection | CPU Protection | ||
BATTERIES (need to be purchased separately) | |||
Battery Type | Lead Acid/Colloid/Lithium Iron phosphate/Ternary Lithium battery (custom) | ||
Charging Method | Three-stage float charge/constant current and constant voltage | ||
Mains Charging Voltage | 12V-three stage float charging:conventional 14.2V、float charging 13.8V、constant current and constant voltage:14.5V 24V-three stage float charging:conventional 28.4V、float charging 27.6V、constant current and constant voltage:14.5V:29V 48V-three stage float charging:conventional 56.8V、float charging 55.2V、constant current and constant voltage:58V 60V-three stage float charging:conventional 71V、float charging 69V、constant current and constant voltage:72.5V 72V-three stage float charging:conventional -85.2V、float charging 82.8V、constant current and constant voltage:87V | ||
Mains Charging Current | 0-30A(12V) 0-15A(24V) 0-7A(48V) | 0-50A(12V) 0-40A(24V) 0-15A(48V) 0-10A(60V) 0-10A(72V) | 0-75A(12V) 0-40A(24V) 0-25A(48V) 0-12A(60V) 0-12A(72V) |
Load Capacity | |||
Resistive Load | Below 1KW | Below 2KW | Below 3KW |
Includes the following 12V 3000W Below 2500W 24V 6000W Below 5000W | |||
Inductive Load | Below350W | Below750W | Below 1100W |
Alarm | |||
Low Battery Alarm | Audible Alarm - 5 seconds beep | ||
Overload Alarm | Audible Alarm - Continuous beep | ||
Fault Alarm | Audible Alarm - Continuous beep | ||
Environment | |||
Temperature | 0-40℃ | ||
Humidity | 0-90% (non-condensing) | ||
Noise | <60dB | ||
Size | |||
Dimensions(Length*width*height cm) | Inverter 49*22*19 | ||
Packaging(length*width*height cm) | inverter 53*26*26 | ||
Inverter Weight KG | 11 | 17 | 20 |
**The above parameters are for reference only. If there are any changes please refer to the actual product
Application
DC to AC inverter, for home, car, enterprise and outdoor use
